Description
The Niglon MCB6B1-10 is a 10A single-pole Type B miniature circuit breaker (MCB) with a 6kA breaking capacity. It protects final circuits against overload and short-circuit faults on a DIN-rail consumer unit or distribution board.
Type B breakers trip at 3–5 times rated current, suited to domestic and resistive loads with low inrush current. Bi-directional connection allows line and load to be wired either way, and it is manufactured to BS EN 60898-1.
Key features
- 10A single-pole Type B MCB
- 6kA breaking capacity
- Type B tripping characteristic (3–5 times rated current)
- Bi-directional line/load connection
- DIN-rail mounting, single module width
- Manufactured to BS EN 60898-1
Specification
- Rated current: 10A
- Tripping curve: Type B
- Poles: 1 (single-pole)
- Voltage rating: 230V
- Breaking capacity: 6kA
- Max. cable capacity: 25mm²
- Standard: BS EN 60898-1
