Description
The DS130VG is an extreme duty Type 1+2+3 AC surge protector device designed to protect at the entrance of the electrical installation. This SPD is particularly useful in a high lightning density area where the risk of heavy surge current or even direct strike is high (eg: buildings equipped with lightning rods). The DS130VG is one-pole SPD and can be used in common mode or common and differential mode. DS130VG AC surge protectors are designed to be connected in multi-pole configuration to protect single-phase, 3-phase and 3-phase+Neutral AC networks, sometimes associated with a dedicated N/PE SPD.
- Type 1+2+3 AC Surge Protector
- Earth type TN
- Max discharge current Imax 50kA 8/20µs
- Impulse current by pole limp 12.5kA 10/350µs
- 230/400VAC Network voltage
- Visual status indicator
- VG-Gas tube spark gap + MOV
- Zero residual leakage & Follow on current
- 18th Edition Complaint
- IEC/EN61643-11 compliant, EAC, UKCA / CE Approved
